105-165 HP
E683 is an EICHER branded in-line 6-cylinder, 4.95-liter engine, with an output-range of 105-156 HP and RPM 1500-2150. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for various marine applications.
Specifications
- Engine-ModelE683
- Output-Range105-165 HP
- Displacement4.95 Liters
- RPM1500-2150
- Emission StandardNot Applicable
Technical SPECIFICATIONs
| Field Set | Features | 105HP -165HP |
|---|---|---|
| Technical specifications | Rated Speed | 1500-2150 RPM |
| Speed Type | Variable/Fixed | |
| Gross Power (HP) | 105-165 | |
| Emission Standards | Emissions Complaint | Not Applicable |
| General | Bore | 100 mm |
| Stroke | 105 mm | |
| Displacement | 4.9 Liters | |
| Aspiration | TC/TCI | |
| Rotation from Flywheel End | Anti-clockwise | |
| Fuel System | Mechanical | |
| Compression Ratio | 17:01 | |
| Cooling System | Liquid | |
| Cycle | 4 stroke | |
| Number of Cylinders | 6-inline | |
| Specification of lube oil | API CI4 Plus -SAE 15W 40 | |
| Total Lubricating Capacity | 17 Liters | |
| Engine Dimensions | Dry Weight | 520 kg |
| Height | 913 mm | |
| Length | 1152 mm | |
| Width | 746 mm |
