56 KW
E483 is an EICHER branded in-line 4-cylinder, 3.3-liter engine, with an output of 56 KW and RPM 2200. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for various marine applications.
Specifications
- Engine Model483
- Output56 KW
- Displacement3.3 Liters
- RPM2200
- Emission StandardCEV IV
Technical SPECIFICATIONs
| Field Set | Features | 56 KW |
|---|---|---|
| Technical specifications | Rated Speed | 2200 |
| Speed Type | Variable | |
| Gross Power (HP) | 74 | |
| Maximum Output (KW) | 56 | |
| Maximum Torque (Nm) | 300 | |
| Emission Standards | Emissions Complaint | CEV IV / V Ready |
| General | Bore | 100 |
| Stroke | 105 | |
| Displacement | 3.3 | |
| Aspiration | Turbocharged | |
| Rotation from Flywheel End | Anti-clockwise, viewed from flywheel | |
| Fuel System | CRDi | |
| Combustion System | Direct Injection | |
| Firing Order | 1-3-4-2 | |
| Minimum Engine Low Idling Speed | 700+/-50 | |
| Maximum Engine Fly up Speed | 2400+/-50 | |
| Compression Ratio | 17:01 | |
| Cooling System | Liquid | |
| Cycle | 4 stroke | |
| Number of Cylinders | 4 | |
| Total Lubricating Capacity ( Liters ) | 13 | |
| Starting System (V) | 12/24 | |
| Charging Alternator (V) | 12/24 | |
| Crank shaft power take-off | Yes (Optional) | |
| Power steering | Yes (Optional) | |
| Air Compressor | Yes (Optional) | |
| Engine Dimensions | Height | 790 |
| Length | 842 | |
| Width | 700 |
