E694 is an EICHER branded in-line 6-cylinder, 5.7-liter engine, with an output-range of 156-259 HP and RPM 1500-2400. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for various marine applications.

E694

Specifications

  • Engine-ModelE694
  • Output-Range156-259 HP
  • Displacement5.7 Liters
  • RPM1500-2400
  • Emission StandardNot Applicable

Technical SPECIFICATIONs

Field Set Features 156HP-259HP
Technical specifications Rated Speed 1500-2400 RPM
Speed Type Variable
Gross Power (HP) 156-259
Emission Standards Emissions Complaint Not Applicable
General Bore 100 mm
Stroke 120 mm
Displacement 5.7 Liters
Aspiration TC/TCI
Rotation from Flywheel End Anti-clockwise
Fuel System Mechanical
Compression Ratio 17.5:01
Cooling System Liquid
Cycle 4 stroke
Number of Cylinders 6-inline
Total Lubricating Capacity 23.8 Liters
Engine Dimensions Height 833 mm
Length 1234 mm
Width 866 mm
