38-131 HP
E483 is an EICHER branded in-line 4-cylinder, 3.3-liter engine, with an output-range of 38-131 HP and RPM 1500-3000. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher bra4242nded engine is the right choice for various marine applications.
Specifications
- Engine-ModelE483
- Output-Range38-131 HP
- Displacement3.3 Liters
- RPM1500-3000
- Emission StandardNot Applicable
Technical SPECIFICATIONs
| Field Set | Features | 38 HP-131 HP |
|---|---|---|
| Technical specifications | Rated Speed | 1500-3000 RPM |
| Speed Type | Variable | |
| Gross Power (HP) | 38-131 | |
| Emission Standards | Emissions Complaint | Not Applicable |
| General | Bore | 100 mm |
| Stroke | 105mm | |
| Displacement | 3.3 Liters | |
| Aspiration | NA/TC/TCI | |
| Rotation from Flywheel End | Anti-clockwise | |
| Fuel System | Mechanical | |
| Compression Ratio | 17:01 | |
| Cooling System | Liquid | |
| Cycle | 4 stroke | |
| Number of Cylinders | 4-inline | |
| Total Lubricating Capacity | 13 Liters | |
| Engine Dimensions | Height | 790mm |
| Length | 842mm | |
| Width | 700mm |
